What is Freeze Drying?
What is Freeze Drying?
Freeze drying (also known as lyophilization) is a water removal process typically used to preserve perishable materials, with the goal of extending their shelf life and/or preparing them for transport. Freeze drying works by freezing the material, then reducing the pressure and adding heat to allow the frozen water in the material to change directly to a vapor (sublimate).
How does Freeze Drying work?
Freeze drying occurs in three phases:
- Primary Drying (Sublimation)
- Secondary Drying (Adsorption)
Proper freeze drying can reduce drying times by 30%
Freezing is the most critical phase of freeze drying, and there are many methods for it. Freezing can be done in a freezer, a chilled bath (shell freezer) or on a shelf in the freeze dryer. Cooling the material below its triple point ensures that sublimation, rather than melting, will occur. This preserves its physical form.
Freeze drying is easiest to accomplish using large ice crystals, which can be produced by slow freezing or annealing. However, with biological materials, when crystals are too large they may break the cell walls, and that leads to less-than-ideal freeze drying results. To prevent this, the freezing is done rapidly. For materials that tend to precipitate, annealing can be used. This process involves fast freezing, then raising the product temperature to allow the crystals to grow.
Primary Drying (Sublimation) Phase
Freeze drying’s second phase is primary drying (sublimation), in which the pressure is lowered and heat is added to the material in order for the water to sublimate. The vacuum speeds sublimation. The cold condenser provides a surface for the water vapor to adhere and solidify. The condenser also protects the vacuum pump from the water vapor. About 95% of the water in the material is removed in this phase. Primary drying can be a slow process. Too much heat can alter the structure of the material.
Secondary Drying (Adsorption) Phase
Freeze drying’s final phase is secondary drying (adsorption), during which the ionically-bound water molecules are removed. By raising the temperature higher than in the primary drying phase, the bonds are broken between the material and the water molecules. Freeze dried materials retain a porous structure. After the freeze drying process is complete, the vacuum can be broken with an inert gas before the material is sealed. Most materials can be dried to 1-5% residual moisture.
Problems To Avoid During Freeze Drying
- Heating the product too high in temperature can cause melt-back or product collapse
- Condenser overload caused by too much vapor hitting the condenser.
- Too much vapor creation
- Too much surface area
- Too small a condenser area
- Insufficient refrigeration
- Vapor choking – the vapor is produced at a rate faster than it can get through the vapor port, the port between the product chamber and the condenser, creating an increase in chamber pressure.
Important Freeze Drying Terms
Here are a few important freeze drying terms. For a comprehensive list, see our freeze drying terminology page.
Eutectic Point or Eutectic Temperature
Is the point at which the product only exists in the solid phase, representing the minimum melting temperature. Not all products have a eutectic point or there may be multiple eutectic points.
During freeze drying, the maximum temperature of the product before its quality degrades by melt-back or collapse.
The material forms crystals when frozen.
- Has a eutectic point or multiple eutectic points
- Fast freezing creates small crystals which are hard to dry
- Annealing can help form bigger crystals
Multi-component mixtures which do not crystallize and do not have a eutectic point. They turn into a ‘glass.’
- Does not have a eutectic point
- For amorphous materials, freeze drying needs to be performed below the glass transition temperature
The point at which the product softens to the extent that it can no longer support its own structure. This can be a problem for many reasons:
- Loss of physical structure
- Incomplete drying
- Decreased solubility
- Lots of ablation (splat)
